Product Profile
This was product was developed specifically for cars that are not equipped with door dump reservoirs. Moisture is removed from the car’s filter bowl each time the doors are closed after the dump sequence preventing excessive water from flowing through the dump valves and cylinders. There are many benefits in using this device all of which are geared towards reducing maintenance costs caused by water and contaminants.
Please click here for more information
Specifications
Body: Anodized Aluminum
Pilot Cap: Anodized Aluminum
Internal Parts: Aluminum and Stainless Steel
Seals: Buna-N Rubber
Temperature Range: -30 degrees F to +250 degrees F
Pressure Rating: 250 PSI
Flow Capacity: 1.4 Cv
Port Size Inlet: ¼” NPT
Outlet: (non-threaded)Pilot Port ¼” NPT
